Machineries

Pagnoni Tools has a wide range of CNC machines, which allow to carry out all the necessary manufacturing steps and to guarantee production efficiency and technological evolution.

CNC milling:

N°15 CNC :
Fanuc, Dah-Lih, Kafo, Leadwell, Mori Seiki.
CNC milling machines allow multiple operations on the workpiece, such as milling, drilling, tapping, boring and contouring.

CNC lathes:

N°15 CNC lathes:
Biglia, Goodway, Angelini. CNC lathes are high-performance systems capable of performing high-precision machining to micron accuracy on the manufactured parts.

External grinding machines:

N°7 external grinding machines:
Morara, Karstens
By the use of grinding machines it is possible to achieve high dimensional accuracies, and surface finishes of extreme quality and precision.

Balancing Machines:

N°2 Haimer Balancing Machine.
The high precision balancing allows to achieve the maximum efficiency of the milling machine, for number of revolutions, milling capacity and quality of the surface produced, as well as a high durability of the spindle.

Tools presetting:

N°1 presetting station M. Conti.
The presetting is an important step to determine the state of wear of the tools, necessary information for a high precision production.

Engineering

Chucks and Polygonal Chucks

A highly qualified team works daily in the pursuit of technological research, evolving products and production processes, and constantly enhancing quality and efficiency in the field of products for mechanical processing, for Chucks and Polygonal Chucks.

Use of advanced CAD/CAM tools:

Parametric CAD: Solidworks 2018 integrated with PDM Professional; Solidedge ST10
CAM: Mastercam 2017

Product development activities:

Project management, utilizing Program management techniques
Consulting at every stage of the project
Product/process feasibility analysis
Product development, starting from customer specifications
3D design and management of complex assemblies
Creation of 2D drawings
Maximum efficiency in data archiving and change management, through integration with Solidworks PDM Professional
